Camera

Image Sensor

<!–{v.name}–>

1/2.7″ CMOS

Max. Resolution

<!–{v.name}–>

3288 (H) x 1850 (V)

ROM

<!–{v.name}–>

256 MB

RAM

<!–{v.name}–>

1 GB

Scanning System

<!–{v.name}–>

Progressive

Electronic Shutter Speed

<!–{v.name}–>

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

<!–{v.name}–>

0.008 lux@F1.6 (Color, 30 IRE)

0.0008 lux@F1.6 (B/W, 30 IRE)

0 lux (Illuminator on)

S/N Ratio

<!–{v.name}–>

>56 dB

Illumination Distance

<!–{v.name}–>

Up to 30 m (98.43 ft) (IR);

Up to 30 m (98.43 ft) (Warm light)

Illuminator On/Off Control

<!–{v.name}–>

Auto;Manual

Illuminator Number

<!–{v.name}–>

4 (Multi-core (IR + warm) light)

Angle Adjustment

<!–{v.name}–>

Pan: –30° to 30°

Tilt: 0° to 80°

Rotation: 0° to 360°

Lens

Lens Type

<!–{v.name}–>

Fixed-focal

Lens Mount

<!–{v.name}–>

M12

Focal Length

<!–{v.name}–>

2.8 mm

Max. Aperture

<!–{v.name}–>

F1.6

Field of View

<!–{v.name}–>

2.8 mm: H: 108.4°; V: 60°; D: 127.1°

Iris Control

<!–{v.name}–>

Fixed

Close Focus Distance

<!–{v.name}–>

2.8 mm: 1.4 m (4.59 ft)

DORI Distance

<!–{v.name}–>

Lens

<!–{v2}–>

Detect

<!–{v2}–>

Observe

<!–{v2}–>

Recognize

<!–{v2}–>

Identify

<!–{v2}–>

<!–{v2}–>

<!–{v2}–>

<!–{v2}–>

<!–{v2}–>

<!–{v2}–>

2.8 mm

<!–{v2}–>

70.3 m

( 230.64 ft)

<!–{v2}–>

28.1 m

( 92.19 ft)

<!–{v2}–>

14.1 m

( 46.26 ft)

<!–{v2}–>

7.0 m

( 22.97 ft)

<!–{v2}–>

Intelligence

IVS (Perimeter Protection)

<!–{v.name}–>

Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human), loitering detection, and stay detection

SMD

<!–{v.name}–>

SMD 4.0

AcuPick

<!–{v.name}–>

Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.

AI SSA

<!–{v.name}–>

Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions.

Face Detection (Full Image)

<!–{v.name}–>

Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face exposure; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.

Smart Search

<!–{v.name}–>

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

AI Coding

<!–{v.name}–>

AI H.264/H.265;

*includes SmartCodec Technology,Smart H.264+ /H.265+

Video Frame Rate

<!–{v.name}–>

Main stream: 3288 x 1850@(1–25/30 fps)

Sub stream: 1920 x 1080@(1–25/30 fps)

Third stream: 1920 x 1080@(1–25/30 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Streaming Capability

<!–{v.name}–>

3 streams

Resolution

<!–{v.name}–>

6M (3288 x 1850/3200 x 1800); 5M (2960 x 1668/2880 x 1620); 4M (2688 x 1520/2560 x 1440); 3M (2304 x 1296); 1080p (1920 x 1080); 720p (1280 x 720); D1 (704 x 576/704 x 480); VGA (640 x 480); CIF (352 x 288/352 x 240)

Bit Rate Control

<!–{v.name}–>

VBR;CBR;ABR

Video Bit Rate

<!–{v.name}–>

H.264: 3 kbps–16384 kbps;

H.265: 3 kbps–16384 kbps

Day/Night

<!–{v.name}–>

Auto(ICR)/Color/B/W

BLC

<!–{v.name}–>

Yes

HLC

<!–{v.name}–>

Yes

WDR

<!–{v.name}–>

120 dB

Scene Self-adaptation (SSA)

<!–{v.name}–>

Yes

White Balance

<!–{v.name}–>

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

<!–{v.name}–>

Auto/Manual

Noise Reduction

<!–{v.name}–>

3D NR

Motion Detection

<!–{v.name}–>

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

<!–{v.name}–>

Yes (4 areas)

Smart Illumination

<!–{v.name}–>

Yes

Smart Dual Light

<!–{v.name}–>

Yes

Defog

<!–{v.name}–>

Yes

Image Rotation

<!–{v.name}–>

0°/90°/180°/270° (Support 90°/270° with 2688 x 1520 resolution and lower)

Mirror

<!–{v.name}–>

Yes

Privacy Masking

<!–{v.name}–>

8 areas

LDC

<!–{v.name}–>

Yes

Audio

Built-in MIC

<!–{v.name}–>

Yes, built-in Mic

Audio Compression

<!–{v.name}–>

PCM; G.711a; G.711Mu; G.726; G.723

Alarm

Alarm Event

<!–{v.name}–>

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; face detection; loitering detection; stay detection; people detection; motor vehicle detection; SMD; security error

Network

Network Port

<!–{v.name}–>

RJ-45 (10/100 Base-T)

SDK and API

<!–{v.name}–>

Yes

Network Protocol

<!–{v.name}–>

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P

Interoperability

<!–{v.name}–>

ONVIF (Profile S & Profile G & Profile T & Profile M); CGI

User/Host

<!–{v.name}–>

20 (Total bandwidth: 64 M)

Storage

<!–{v.name}–>

FTP; SFTP; Micro SD card (support max. 512 GB); NAS

Browser

<!–{v.name}–>

IE: IE11;

Chrome;

Firefox

Management Software

<!–{v.name}–>

Smart PSS Lite; DSS; DMSS; DoLynk Care

Mobile Client

<!–{v.name}–>

iOS;Android

Security

<!–{v.name}–>

Video encryption;Firmware encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning

Certification

Certifications

<!–{v.name}–>

CE-LVD: EN62368-1;

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Port

Audio Input

<!–{v.name}–>

1 channel (RCA port)

Audio Output

<!–{v.name}–>

1 channel (RCA port)

Alarm Input

<!–{v.name}–>

1 channel in: supports wet contact connection (max load 5 mA 3–5 VDC); supports dry contact connection

Alarm Output

<!–{v.name}–>

1 channel out: wet contact, max load 300 mA 12 VDC

Power

Power Supply

<!–{v.name}–>

12 VDC (±30%); PoE (802.3af)

Power Consumption

<!–{v.name}–>

Basic: 3.8 W (12VDC); 8.7 W (PoE);

Max.: 4.6 W (12 VDC); 10.1 W (PoE) (H.265 + WDR + warm light + intelligence on)

Environment

Operating Temperature

<!–{v.name}–>

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

<!–{v.name}–>

? 95% (RH), non-condensing

Storage Temperature

<!–{v.name}–>

–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity

<!–{v.name}–>

? 95% (RH), non-condensing

Protection

<!–{v.name}–>

IP67; IK10

Anti-corrosion Level

<!–{v.name}–>

Basic Protection

*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.

Structure

Casing Material

<!–{v.name}–>

Metal

Product Dimensions

<!–{v.name}–>

64.8 mm x D111.0 mm (2.55″ x D4.37″)

Net Weight

<!–{v.name}–>

423 g (0.93 lb)

Gross Weight

<!–{v.name}–>

590 g (1.30 lb)
