Standalone access control with integrated keypad and card reader, 125KHz EM, IP66, Wi-Fi, Tuya.
Features:This is a compact standalone access control unit with a keypad and proximity card reader, supporting control via the Tuya (Smart Life / Tuya Smart) app over Wi-Fi.Multiple access modes: using a smartphone (with the Tuya app), RFID card, or PIN code.Remote management is performed via the Tuya smart app (on a phone or tablet): you can conveniently add or delete users, set time restrictions, create temporary (one-time or periodic) codes, view door opening logs, and enable the Door Keep Open mode.Remote access via mobile internet (3G/4G/5G) is supported.The RFID access control is designed for extreme weather conditions (-40°C~+60°C), suitable for outdoor as well as indoor use.Metal case anti-vandal. Anti-tamper alarm.Backlit keypad for use in the dark.Supports 10 visitor users with 1 to 10 entries.Two special panic users for situations where a person is forced to enter normally but wants to signal a threat. The door is unlocked by card or PIN, while the system secretly sends an alarm signal.Supports 125KHz EM cards.
&#x4;Technical specification:&#x4;Number of users (cards/PINs): 10.000 (9988 common users + 10 visitors + panic users).&#x4;Number of mobile users: 500.&#x4;PIN length: 4-6 digits.&#x4;Supported card frequency: 125 kHz EM.&#x4;Operating voltage: 12 V DC.&#x4;Idle current: <60mA.&#x4;Active current: <150mA.&#x4;Card reading distance: 2~6 cm.&#x4;Protocol: Wiegand 26/44 bit.&#x4;App: Tuya Smart / Smart Life (Android, iOS).&#x4;Number of doors supported: 1.&#x4;Wiring connections: relay output, exit button, alarm, door contact, Wiegand input/output.&#x4;Relay: 1 (lock relay, NO/NC/COM contacts).&#x4;Adjustable relay output time: 0–99 seconds (default 5 seconds).&#x4;Lock output load: up to 2 A.&#x4;Mounting: wall-mounted.&#x4;Material: zinc alloy.&#x4;Safety class: IP66.&#x4;Operating temperature: -40°C to +60°C.&#x4;Relative humidity: 0%–98% RH.&#x4;Dimensions: 117 x 70 x 22 mm.&#x4;Weight: 415 g.&#x4;Color: silver, black.&#x4;
.&#x4;Warranty: 24 months.&#x4;
